Conspit ARES Platinum 20 Nm Direct Drive Base

Sale price $1,049.00 CAD
Available now at PassionSim

The CONSPIT ARES Platinum 20 Nm Direct Drive Base delivers an immersive racing simulation experience with exceptional precision and responsiveness.

Don't miss the deal

000
00 Days
00
00 Hours
00
00 Mins
00
00 Secs
Hurry, only 1 items left in stock!

Pickup available at Boutique PassionSim

Usually ready in 24 hours

Available locations

Conspit ARES Platinum 20 Nm Direct Drive Base

Conspit ARES Platinum 20 Nm Direct Drive Base

  • Boutique PassionSim

    Pickup available, usually ready in 24 hours

    990 Rue des Ibis, Québec QC G3K 1L7, Canada

    +15819805653
    Get direction
Free shipping over $200
Support technique 24/7
Established brand
20 Nm
encodeur
23-bit encoder
charge
7.9 kg
USB 3.0
PC Compatible
connexion
Quick Release
garantie
Manufacturer Warranty
Complete your cockpit

Here is what makes it usable: a wheel, the CDP quick release on the wheel side, pedals and an emergency stop.

This item
Conspit ARES Platinum 20 Nm Direct Drive Base
Wheel
Conspit 300GT Steering Wheel300 mm GT wheel in carbon and aluminium, 2.99" display and 48 LEDs: 1,150 g without quick release.View product
$601.00
Wheel-side quick release
Conspit CDP Quick ReleaseThe system for ARES 12 and 20 bases. Conspit wheels are sold without a quick release.View product
$95.00
Pedals
Conspit CPP EVO V2 Hydraulic PedalsUp to 200 bar, 20 MPa sensor, built-in M-DVF vibration module.View product
$937.00
Safety
Conspit CES E-Stop Emergency SwitchCuts power with a single press. Essential safety as soon as you drive a high-torque base.View product
$69.00
Cockpit mounting
Conspit ARES Base Stand for Aluminium ProfileARES base support for aluminium-profile cockpits, no extra drilling.View product
$55.00
Bundle total

In detail

CONSPIT ARES Platinum 20 Nm Direct Drive Base: performance and precision for demanding pilots

Conspit ARES Platinum 20 Nm Direct Drive Base 01 / 04

Dual rotor bias pole motor

The dual-rotor biased pole motor is specifically designed for racing simulation, providing fast and precise response to steering inputs.

CONSPIT ARES Platinum 20 Nm — base direct drive, vue 2 02 / 04

High precision optical encoder

The 23-bit optical encoder provides angular resolution of less than 0.01°, capturing every steering movement with exceptional precision.

03 / 04

Ultra-fast torque response

With a torque response of 9.5 Nm/ms, the ARES Platinum 20 Nm base provides smooth and responsive force feedback, enhancing immersion and control.

04 / 04

Aircraft-grade aluminum construction

The aircraft-grade aluminum housing provides maximum rigidity and efficient heat dissipation, ensuring consistent performance.

Features

  • 20 Nm of peak torque: force feedback that carries weight transfer without clipping
  • Skew-pole dual-rotor Direct Drive motor developed for sim racing
  • 23-bit high-resolution optical encoder: angular resolution under 0.01°
  • 9.5 Nm/ms torque response for instant feel on mid-corner corrections
  • Aerospace-grade aluminium housing: maximum rigidity and effective heat dissipation
  • CONSPIT CDP quick release to swap wheels in seconds
  • Direct USB connection and full control through CONSPIT LINK 2.0

Technical Specs

General
Brand CONSPIT
Model ARES 20 Platinum
Type Direct Drive wheelbase
Dimensions 134 x 150 x 287 mm
Net weight 7.9 kg
Motor & force feedback
Maximum torque 20 Nm
Motor Skew-Pole Direct Drive, dual rotor
Encoder 23-bit high-resolution optical
Torque response 9.5 Nm/ms
Mounting
Quick release CONSPIT CDP Quick Release System
Mounting M6 x 4 (bottom), M8 x 4 (sides)
Emergency stop CES E-Stop (optional)
Connectivity & compatibility
Platform PC (Windows)
Connection Direct USB
Cable USB 3.0 cable included
Software CONSPIT LINK 2.0

Buying guides

Written by a sim racer, to help you compare before you buy.

All guides →
Conspit quick release guide: CDR, CDP, Quick-Con and mixing brands Guide Conspit quick release guide: CDR, CDP, Quick-Con and mixing brands Read the guide → Direct drive wheel: how many Nm do you actually need? Guide Direct drive wheel: how many Nm do you actually need? Read the guide → Sim racing for beginners: how to choose your first setup Guide Sim racing for beginners: how to choose your first setup Read the guide →

FAQ

A few questions we're often asked about this product.

Our team of experts is here to answer any question you have.

Yes, it's essential. At 20 Nm this is among the most powerful bases available: on a desk clamp or a light stand, the structure absorbs part of the torque and you lose what you paid for. An aluminium extrusion chassis with a front or side mount is the right partner.

Headroom. Its 20 Nm reproduce the load of a fast corner and the front axle letting go without clipping the peaks, where a 12 Nm base sometimes saturates. The dual-rotor skew-pole motor and 23-bit optical encoder translate micro-movements with no stepping and no dead zone at centre.

134 x 150 x 287 mm at 7.9 kg, bolting down with four M6 screws underneath or four M8 screws on the sides. It connects over direct USB with a USB 3.0 cable, is configured in CONSPIT LINK 2.0 on Windows, and takes wheels through the CDP quick release.
