Sim Racing Cockpit | 6S-160 V2 | 6SIGMA
Available at PassionSim
The 6SIGMA 6S-160 V2 is the largest cockpit in the range: CNC-machined 40-series aluminium extrusion, 130 x 65 x 78 cm and 50 kg, built for direct drive wheelbases up to 30 Nm. Its flex-free frame keeps every torque peak in your hands, with a front wheel mount adjustable for angle, an adjustable pedal plate, and a shifter mount and mouse pad kit included.
Pickup available at Boutique PassionSim
Usually ready in 24 hours
Complete your cockpit
The 6S-160 V2 is built for high-end bases up to 30 Nm. Here is what to fit on it.
This item

Sim Racing Cockpit | 6S-160 V2 | 6SIGMA
Seat


Seat | ERS3 Elite Reclining Seat | NEXT LEVEL RACINGReclining seat built for endurance, slides and hardware included.View product
$350.00

Seat | ERS4 Elite Reclining Seat | NEXT LEVEL RACINGReclining seat officially licensed by the FIA, bottom-mounted.View product
$419.00

Seat | PRS1 Performance Reclining Seat | NEXT LEVEL RACINGWrap-around support inspired by supercar seats, with a reclining backrest.View product
$559.00
Screens

6S Triple Monitor Stand | 6SIGMAAluminium triple monitor stand, up to 43" per screen, expandable to four screens.View product
$546.00

VESA Monitor Mount | Micro Adjustment Mount | 6SIGMAVESA 75 x 75 and 100 x 100 mm mount with micro-adjustment.View product
$170.00
Legs

Accessory | 6S Cockpit Support | 6SIGMAReinforced 15 mm aluminium legs, adjustable up to 15 cm, for the 6S-80, 6S-120 and 6S-160.View product
$150.00
Bundle total
In detail
6SIGMA 6S-160 V2: the high-end cockpit for powerful direct drive
01 / 04
02 / 04
A driving position adjustable end to end
03 / 04
Built for high-end wheelbases
04 / 04
A platform that grows with you
Features
- CNC-machined 40-series aluminium extrusion, matte black finish, flex-free frame
- 50 kg of structure: the heaviest and most stable cockpit in the 6SIGMA range
- Built for high-end direct drive wheelbases up to 30 Nm
- Front wheel mount, adjustable for angle, in full-profile aluminium
- Adjustable pedal plate: 10 cm aluminium side plates and 40-series crossbar
- Shifter mount and mouse pad kit included
- Modular structure compatible with 6SIGMA monitor stands and accessories
Technical Specs
| General | |
|---|---|
| Brand | 6SIGMA |
| Model | 6S-160 V2 |
| Type | Aluminium extrusion sim racing cockpit |
| Dimensions | 130 x 65 x 78 cm (L x W x H) |
| Weight | 50 kg |
| Material | CNC-machined 40-series aluminium, matte black finish |
| Structure | Rigid flex-free frame, modular |
| Adjustments | |
| Wheel mount | Front mounted, adjustable for angle |
| Pedal plate | Adjustable, 10 cm aluminium side plates and 40-series crossbar |
| Seat | Seat and rails sold separately |
| Compatibility | |
| Supported torque | Direct drive wheelbases up to 30 Nm |
| Pedals | Load cell and hydraulic |
| Accessories | Single or triple monitor stands, keyboard tray, PC mount |
| Contents | |
| Included | Shifter mount and mouse pad kit |
| Assembly | About 2 hours |
Buying guides
Written by a sim racer, to help you compare before you buy.
FAQ
A few questions we're often asked about this product.
Our team of experts is here to answer any question you have.
What is the difference between the 6S-80, 6S-120 and 6S-160 V2 cockpits?
Which direct drive base can be mounted on the 6S-160 V2?
Is a seat included with the 6S-160 V2 cockpit?
